Filtermart™ CARBON ELEMENT

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Add To Cart

FMC #13-0035

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Adsorption Filters/Carbon

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.00
  Beta Rating:	N/A
  Collapse Pressure Rating:	75 PSID
  Maximum Temperature:	120 DEG F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	15 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	11.00 IN (279.40 MM)
  (B) Outer Diameter, Bottom:	11.00 IN (279.40 MM)
  (C) Inner Diameter, Top:	2.06 IN (52.32 MM)
  (D) Inner Diameter, Bottom:	2.06 IN (52.32 MM)
  (E) Length:	22.25 IN (52.32 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	EPOXY
  Type of Endcap:	CARBON STEEL
  Center Tube:	CARBON STEEL
  Type of Media:	CARBON
  Filter Area:	16 X 10 SQ.METERS
  Plating:	NONE
  Outer Jacket:	YES
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	32.00 LB (14.51 KG)
