Filtermart™ STACKED DISK ELEMENT

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Add To Cart

FMC #28-0510

$ 54.54 Each

This product usually ships in 24-48 hours

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*4 per carton

*Contact us to check availability of broken cases

*Special Pricing – (limited qty), additional discounts do not apply

Industrial Filters/General Purpose Filters/Miscellaneous

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	10.00 NOMINAL
  Beta Rating:	N/A
  Collapse Pressure Rating:	75 PSID
  Maximum Temperature:	225 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	6.63 IN (168.40 MM)
  (B) Outer Diameter, Bottom:	6.63 IN (168.40 MM)
  (C) Inner Diameter, Top:	2.50 IN (63.50 MM)
  (D) Inner Diameter, Bottom:	2.50 IN (63.50 MM)
  (E) Length:	16.06 IN (63.50 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	CORK
  Type of Adhesive:
  Type of Endcap:	PLATED STEEL
  Center Tube:	NONE
  Type of Media:	PAPER
  Filter Area:	SQ.IN.
  Plating:	ELECTROTIN PLATED
  Outer Jacket:	NONE - NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	4
  Carton Weight:	23.00 LB (10.43 KG)
