All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
*4 per carton
Industrial Filters/General Purpose Filters/Miscellaneous
Micron Rating: | 0.30 ABSOLUTE |
Beta Rating: | N/A |
Collapse Pressure Rating: | 75 PSID |
Maximum Temperature: | 300 F |
Direction of Flow: | INSIDE->OUT |
Recommended Changeout Differential Pressure: | 20 PSID |
(A) Outer Diameter, Top: | 3.30 IN (83.82 MM) |
(B) Outer Diameter, Bottom: | 3.30 IN (83.82 MM) |
(C) Inner Diameter, Top: | 1.90 IN (48.26 MM) |
(D) Inner Diameter, Bottom: | 1.90 IN (48.26 MM) |
(E) Length: | 24.00 IN (48.26 MM) |
(F) Thread: | NONE |
Handle: | NONE |
Seal Material: | VITON |
Type of Adhesive: | N/A |
Type of Endcap: | CARBON STEEL |
Center Tube: | CARBON STEEL |
Type of Media: | MICROGLASS |
Filter Area: | N/A |
Plating: | N/A |
Outer Jacket: | YES |
Configuration: | SINGLE OPEN END |
Number per Carton: | 4 |
Carton Weight: | 14.00 LB (6.35 KG) |
