All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/General Purpose Filters/Miscellaneous
Micron Rating: | 1.00 ABSOLUTE |
Beta Rating: | |
Collapse Pressure Rating: | |
Maximum Temperature: | 248 F |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 0 PSID |
(A) Outer Diameter, Top: | 2.25 IN (57.15 MM) |
(B) Outer Diameter, Bottom: | 2.25 IN (57.15 MM) |
(C) Inner Diameter, Top: | 0.38 IN (9.65 MM) |
(E) Length: | 10.88 IN (0.00 MM) |
(F) Thread: | N/A |
Handle: | NONE |
Seal Material: | BUNA N |
Type of Adhesive: | |
Type of Endcap: | GLASS FILLED NYLON |
Center Tube: | 316 SS |
Type of Media: | MICROGLASS |
Filter Area: | SQ.IN" |
Plating: | |
Outer Jacket: | NONE |
Configuration: |
Number per Carton: | 1 |
Carton Weight: | 0.50 LB (0.23 KG) |
