All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/General Purpose Filters/Miscellaneous
Micron Rating: | 0.90 |
Beta Rating: | N/A |
Collapse Pressure Rating: | 150PSI |
Maximum Temperature: | 225F |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 20 PSID |
(A) Outer Diameter, Top: | 9.00 IN (228.60 MM) |
(B) Outer Diameter, Bottom: | 9.00 IN (228.60 MM) |
(C) Inner Diameter, Top: | 7.25 IN (184.15 MM) |
(D) Inner Diameter, Bottom: | 7.25 IN (184.15 MM) |
(E) Length: | 26.06 IN (184.15 MM) |
(F) Thread: | NONE |
Handle: | NONE |
Seal Material: | URETHANE |
Type of Adhesive: | N/A |
Type of Endcap: | URETHANE / STEEL |
Center Tube: | PLATED STEEL |
Type of Media: | CELLULOSE |
Filter Area: | N/A |
Plating: | N/A |
Outer Jacket: | YES |
Configuration: | SINGLE W/ BOLT HOLE |
Number per Carton: | 1 |
