All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/General Purpose Filters/Miscellaneous
Micron Rating: | 12.00 ABSOLUTE |
Beta Rating: | N/A |
Collapse Pressure Rating: | 290 PSID |
Maximum Temperature: | 300 F MAX |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 20 PSID |
(A) Outer Diameter, Top: | 1.75 IN (44.45 MM) |
(B) Outer Diameter, Bottom: | 1.75 IN (44.45 MM) |
(C) Inner Diameter, Top: | 1.02 IN (25.91 MM) |
(E) Length: | 8.15 IN (0.00 MM) |
(F) Thread: | N/A |
Handle: | NONE |
Seal Material: | EPR |
Type of Adhesive: | EPOXY |
Type of Endcap: | PLATED STEEL |
Center Tube: | SS |
Type of Media: | MICROGLASS |
Filter Area: | SQ.IN. |
Plating: | SS |
Outer Jacket: | NONE - N/A |
Configuration: | SINGLE OPEN END |
Number per Carton: | 1 |
