51-0014 Portable Filtration System

High Performance Filtration for Today's Industry

600 GPH

Specifications

  • 1 HP TEFC Heavy Duty Motor with Thermal Overload Protection
  • 10 GPM Mechanically sealed positive displacement gear pump with internal relief valve
  • One (1) polyurethane powder baked 51-0002 element housing
  • Wired 110 Volt, 1 phase with all electrical components mounted in a NEMA 4 enclosure
  • Manufactured with automatic high pressure shutdown system for unattended operation
  • 0-100 PSI glycerin filled gauge for monitoring system pressure
  • Plumbed with 3/4" brass fittings and 2000 PSI high pressure steel braided hydraulic hose with crimped hose ends
  • Two (2) 15 ft -3/4" inlet and outlet hydraulic hoses with hose ends
  • Fifteen (15) feet of heavy duty 12/3 power cable
  • Manufactured with 3-way ball valves for fluid fransfer system and to allow for adding makeup oil.
  • Suction-Wye Strainer to protect pump from large debris
  • Heavy duty 12" pneumatic tires
  • Filtration Capacity of 10 GPM with Fluid Transfer Setup

Applications

Hydrolic Oil • Compressor Oil • Quench Oil • EDM Oil • Lubricating Oil • Insulating Oil • Turbine Oil • Gear Oil • Water Glycol Fluids • Water Based Coolants
