Filtermart™ PLEATED MICROGLASS ELEMENT

Add To Cart

FMC #05-1253

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Liquid Filters/Pleated Synthetic/Microglass

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	10.00 ABSOLUTE
  Beta Rating:
  Collapse Pressure Rating:	145 PSI
  Maximum Temperature:	248 F
  Direction of Flow:	INSIDE-->OUT
  Recommended Changeout Differential Pressure:	50 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	2.84 IN (72.14 MM)
  (B) Outer Diameter, Bottom:	2.84 IN (72.14 MM)
  (C) Inner Diameter, Top:	1.77 IN (44.96 MM)
  (D) Inner Diameter, Bottom:	0.33 IN (8.38 MM)
  (E) Length:	2.17 IN (8.38 MM)
  (F) Thread:

• Physical Specifications

  Handle:	NONE
  Seal Material:
  Type of Adhesive:
  Type of Endcap:	PLATED STEEL
  Center Tube:
  Type of Media:	MICROGLASS
  Filter Area:	82 SQ IN
  Plating:
  Outer Jacket:	YES
  Configuration:	SINGLE OPEN W/ BH

• Packaging Specifications

  Number per Carton:

  1
