All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Coalescer Filters/Air/Borosilicate Glass
| Micron Rating: | 0.70 |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | 150 PSID |
| Maximum Temperature: | 225 F |
| Direction of Flow: | INSIDE->OUT |
| Recommended Changeout Differential Pressure: | 15 PSID |
| (A) Outer Diameter, Top: | 9.07 IN (230.38 MM) |
| (B) Outer Diameter, Bottom: | 9.07 IN (230.38 MM) |
| (C) Inner Diameter, Top: | 6.94 IN (176.28 MM) |
| (D) Inner Diameter, Bottom: | 6.94 IN (176.28 MM) |
| (E) Length: | 25.10 IN (176.28 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | URETHANE |
| Type of Adhesive: | N/A |
| Type of Endcap: | URETHANE |
| Center Tube: | CARBON STEEL |
| Type of Media: | BOROSILICATE |
| Filter Area: | N/A |
| Plating: | N/A |
| Outer Jacket: | YES |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 1.00 LB (0.45 KG) |
