All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Coalescer Filters/Air/Borosilicate Glass
| Micron Rating: | 0.30 |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | 70 PSID |
| Maximum Temperature: | 225 F. |
| Direction of Flow: | INSIDE->OUT |
| Recommended Changeout Differential Pressure: | 15 PSID |
| (A) Outer Diameter, Top: | 6.00 IN (152.40 MM) |
| (B) Outer Diameter, Bottom: | 6.00 IN (152.40 MM) |
| (C) Inner Diameter, Top: | 4.00 IN (101.60 MM) |
| (D) Inner Diameter, Bottom: | 4.00 IN (101.60 MM) |
| (E) Length: | 38.00 IN (101.60 MM) |
| (F) Thread: |
| Handle: | NONE |
| Seal Material: | |
| Type of Adhesive: | URETHANE |
| Type of Endcap: | URETHANE |
| Center Tube: | PLATED STEEL |
| Type of Media: | |
| Filter Area: | SQ.IN. |
| Plating: | ZINC PLATED |
| Outer Jacket: | YES |
| Configuration: |
| Number per Carton: | 1 |
| Carton Weight: | 10.00 LB (4.54 KG) |
