Filtermart™ AIR - HIGH TEMP. ELEMENT

Add To Cart

FMC #20-0003

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*6 per carton

Industrial Filters/Coalescer Filters/Air/Borosilicate-Particulate High Temperature

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.30 ABSOLUTE
  Beta Rating:	N/A
  Collapse Pressure Rating:	100 PSIG
  Maximum Temperature:	450 F
  Direction of Flow:	INSIDE->OUT
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	3.32 IN (84.33 MM)
  (B) Outer Diameter, Bottom:	3.32 IN (84.33 MM)
  (C) Inner Diameter, Top:	2.49 IN (63.25 MM)
  (D) Inner Diameter, Bottom:	2.49 IN (63.25 MM)
  (E) Length:	13.19 IN (63.25 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	SILICONE
  Type of Adhesive:	N/A
  Type of Endcap:	PLATED STEEL
  Center Tube:	PLATED STEEL
  Type of Media:	MICROGLASS
  Filter Area:	N/A
  Plating:	N/A
  Outer Jacket:	NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:

  6
